Introduction
AMM-520 Pro is a wet and dry integrated multi-functional milling machine, with a stable structure and various fixture combinations, meeting different production needs.
Webinar with Duff Wilson, CDT | July 11th, 2025
Aidite AMM-520 Pro Highlights
Parameter
| Number of axes | 5 axes |
| Milling mode | Wet and dry |
| Processing type | Crown/bridge, veneer, inlay, customer abutment, implant superstructures (optional module of CAM software), implant bar clip (optional module of CAM software), screw-retained bridge (optional module of CAM software), complete denture, occlusal splint, partial denture framework |
| Millable material | Zirconia, PMMA, Glass ceramic, Premill, PEEK, Titanium disc, CoCr, Composite material |
| Material thickness | 10-35mm (Disc) |
| Accessories | Work table, water cooler, water tank |
| Repeat positioning accuracy | ±5um |
| Linear drive system | Linear guide and lead screw |
| Rotary drive system | Harmonic reducer |
| Clamping system | Zero-point clamping system |
| Control system | Embedded CNC system and AC bus servo motor |
| Machine size | 590×730×820 (mm) |
| Machine weight | 180kg |
| Tool changer | 18 detachable modular design |
| Standard fixture | Disc fixture,C type fixture and block fixture |
| Processing time | Single crown ≤15min, Premill ≤20min Glass ceramic≤20min, full denture≤1.5h |
| Travel | XYZ axis:180X110x100 (mm) A-axis:±361° B-axis:±30° |
| Spindle | Power: AC 2500W Cooling: water cooling Speed: 60000rpm Chuck size: Φ6 mm |
| Input | Power supply: single-phase AC 220V 50/60Hz Voltage Power: 3KW 15A Air pressure: 6Bar |
MACHINABLE APPLICATION
